Signal Refresh Rate (Hz) Resolution (dots)

SVGA 60 800x600

XGA 60 1024x768

WXGA 60 1280x800

SXGA

60 1280x960

60 1280x1024

SXGA+ 60 1400x1050

UXGA 60 1600x1200

SDTV

(480i

/480p)

60 720x480

SDTV

(576i

/576p)

50 720x576

HDTV (720p) 50/60 1280x720

HDTV (1080i) 50/60 1920x1080

HDTV (1080p) 24

/30

/50/60 1920x1080

* HDMI input only
