Epson EB-W28 User Manual

Installing the Wireless LAN Unit
By installing the supplied or optional wireless LAN unit, you can project
the computer screen that is connected to the wireless LAN over a network.
Connect the wireless LAN unit to the projector's USB-A port.
a
• When connecting to the network using wireless LAN, make sure you
make network settings from the Configuration menu.
s "Wireless LAN menu" p.89
• If you normally leave the wireless LAN unit installed, make sure you
attach the supplied wireless LAN unit cover as a theft deterrent.
• When moving the projector, make sure you remove the wireless
LAN unit and cover for safety reasons.
a
Use a cross-head screwdriver to remove the screw that secures the
wireless LAN unit cover.
b
Connect the wireless LAN unit to the USB-A port.
c
Attach the wireless LAN unit cover, and secure it in place with the
screw.
Installing the Quick Wireless Connection USB Key
When installing the optional Quick Wireless Connection USB Key, you
need to remove the Wireless LAN unit first, and then connect the Quick
Wireless Connection USB Key to the USB-A port.
Connecting Equipment
28

Epson EB-W28 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.68 - 2.02 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Screen size compatibility	33 - 320 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.3 - 1.56:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.58 - 1.72
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Analog signal format system	-
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
RMS rated power	2 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	270 W
Power consumption (PowerSave)	201 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 60 %
Cables included	AC, USB
Remote control type	IR
Pallet width	800 mm
Pallet height	2230 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	365 mm
Package width	360 mm
Package height	160 mm
Package weight	3980 g
