• Port Number
Displaying the Web Control screen
Use the following procedure to display the Web Control screen.
Make sure the computer and projector are connected to the network. When
communicating with a wireless LAN, connect in Advanced mode.
a
If your Web browser is set up to connect via a proxy server, the Web
Control screen cannot be displayed. To display Web Control, you need
to make settings so that a proxy server is not used for a connection.
a
Start a Web browser on the computer.
b
Enter the IP address of the projector in the address input box of
the Web browser, and press the Enter key on the computer's
keyboard.
The Web Control screen is displayed.
When Web Control Password is set from the Configuration menu,
the password entry screen is displayed.
c
Enter the user ID and password.
Enter "EPSONWEB" as the user ID.
The initial password is "admin".
a
• Enter the user ID even if a password has not been set. You
cannot change the user ID.
• You can change the password in Network menu from the
Configuration menu.
s Network - Basic - Web Control Password p.89
Displaying the Web Remote screen
The Web Remote function allows you to perform projector remote control
operations with a Web browser.
a
Display the Web Control screen.
b
Click Web Remote.
c
The Web Remote screen is displayed.
Name Function
A
Power button
[t]
Turns the projector power on or off.
s "From Installation to Projection" p.31
Monitoring and Controlling
73

Epson EB-W28 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.68 - 2.02 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Screen size compatibility	33 - 320 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.3 - 1.56:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.58 - 1.72
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Analog signal format system	-
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
RMS rated power	2 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	270 W
Power consumption (PowerSave)	201 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 60 %
Cables included	AC, USB
Remote control type	IR
Pallet width	800 mm
Pallet height	2230 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	365 mm
Package width	360 mm
Package height	160 mm
Package weight	3980 g
