Each time you press the [A/V Mute] button or open/close the lens cover,
A/V Mute turns on or off.
Remote control Projector
a
When projecting moving images, the images and sound continue to
be played back while A/V Mute is on. It is not possible to resume
projection from the point where A/V Mute was activated.
You can select the screen displayed when the [A/V Mute] button is
pressed from the Configuration menu.
s Extended - Display - A/V Mute p.85
When A/V mute is enabled with the [A/V Mute] button, A/V Mute
Timer activates and the power is automatically turned off after
approximately 30 minutes. If you do not want to enable A/V Mute
Timer, set A/V Mute Timer to Off.
s
ECO - A/V Mute Timer p.94
When the A/V mute slide is closed for approximately 30 minutes,
Lens Cover Timer activates and the power is automatically turned
off. If you do not want Lens Cover Timer to activate, set Lens
Cover Timer to Off.
s ECO - Lens Cover Timer p.94
The lamp is still lit during A/V Mute, so the lamp hours continue to
accumulate.
Freezing the Image (Freeze)
When Freeze is activated on moving images, the frozen image continues to
project on the screen, so you can project a moving image one frame at a
time like a still photo. Also, you can perform operations such as changing
between files during presentations from a computer without projecting any
images if the Freeze function is activated beforehand.
Each time you press the [Freeze] button, Freeze turns on or off.
Remote control
a
Audio does not stop.
When projecting moving images, the images continue to be played
back while the screen is frozen. It is not possible to resume
projection from the point where the screen was frozen.
If the [Freeze] button is pressed while the Configuration menu or
the Help screen is displayed, the menu or the Help screen that is
displayed is closed.
Freeze still works while E-Zoom is being used.
Pointer Function (Pointer)
This allows you to move a Pointer icon on the projected image, and helps
you draw attention to the area you are talking about.
Projection Functions
58

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W28 and is the answer not in the manual?

Epson EB-W28 Specifications

General IconGeneral
Number of colors1.073 billion colors
Native aspect ratio16:10
Projection distance1.68 - 2.02 m
Vertical scan range50 - 85 Hz
Projection technology3LCD
Contrast ratio (typical)10000:1
Screen size compatibility33 - 320 \
Projector native resolutionWXGA (1280x800)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2100 ANSI lumens
FocusManual
Throw ratio1.3 - 1.56:1
Zoom capabilityYes
Focal length range16.9 - 20.28 mm
Aperture range (F-F)1.58 - 1.72
Lamp power200 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)6000 h
Full HDNo
Analog signal format system-
USB connector typeUSB Type-A, USB Type-B
USB 2.0 ports quantity2
Noise level37 dB
Country of originChina
Noise level (economic mode)29 dB
RMS rated power2 W
PlacementDesktop
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.28 W
Power consumption (typical)270 W
Power consumption (PowerSave)201 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 60 %
Cables includedAC, USB
Remote control typeIR
Pallet width800 mm
Pallet height2230 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth234 mm
Width297 mm
Height77 mm
Weight2400 g
Package depth365 mm
Package width360 mm
Package height160 mm
Package weight3980 g
