a
If Password Protect is already activated, you must enter the
password.
If the password is entered correctly, the Password Protect
setting menu is displayed.
s "Entering the Password" p.68
When the password is set, stick the password protect sticker
in a visible position on the projector as a further theft
deterrent.
s Password Protect Sticker
b
Select the type of Password Protect you want to set, and then
press the [
] button.
c
Select On, and then press the [ ] button.
Press the [Esc] button, the screen displayed in step 2 is displayed
again.
d
Set the password.
(1)
Select Password, and then press the [
] button.
(2)
When the message "Change the password?" is displayed, select Yes and
then press the [
] button. The default password is set to "0000". Change
this to your own desired Password. If you select No, the screen displayed
in step 2 is displayed again.
(3) While holding down the [Num] button, enter a four digit number using
the numeric buttons. The number entered is displayed as "* * * *". When
you enter the fourth digit, the confirmation screen is displayed.
Remote control
(4) Re-enter the password.
The message "Password accepted." is displayed.
If you enter the password incorrectly, a message is displayed prompting
you to re-enter the password.
Entering the Password
When the password entry screen is displayed, enter the password using the
remote control.
While holding down the [Num] button, enter the password by pressing the
numeric buttons.
Security Functions
68

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W28 and is the answer not in the manual?

Epson EB-W28 Specifications

General IconGeneral
Number of colors1.073 billion colors
Native aspect ratio16:10
Projection distance1.68 - 2.02 m
Vertical scan range50 - 85 Hz
Projection technology3LCD
Contrast ratio (typical)10000:1
Screen size compatibility33 - 320 \
Projector native resolutionWXGA (1280x800)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2100 ANSI lumens
FocusManual
Throw ratio1.3 - 1.56:1
Zoom capabilityYes
Focal length range16.9 - 20.28 mm
Aperture range (F-F)1.58 - 1.72
Lamp power200 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)6000 h
Full HDNo
Analog signal format system-
USB connector typeUSB Type-A, USB Type-B
USB 2.0 ports quantity2
Noise level37 dB
Country of originChina
Noise level (economic mode)29 dB
RMS rated power2 W
PlacementDesktop
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.28 W
Power consumption (typical)270 W
Power consumption (PowerSave)201 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 60 %
Cables includedAC, USB
Remote control typeIR
Pallet width800 mm
Pallet height2230 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth234 mm
Width297 mm
Height77 mm
Weight2400 g
Package depth365 mm
Package width360 mm
Package height160 mm
Package weight3980 g
