a
Press the [ ][ ] buttons to move to the next or previous
image file.
d
To finish projecting, perform one of the following operations.
Projecting an image: Press the [Esc] button.
Projecting a movie: Press the [Esc] button to display the message
screen, select Exit, and then press the [
] button.
When projection is finished, you are returned to the file list screen.
Projecting image files in a folder in sequence (Slideshow)
You can project the image files in a folder in sequence, one at a time. This
function is called Slideshow. Use the following procedure to run
Slideshow.
a
To change files automatically when you run Slideshow, set Screen
Switching Time from Option to anything other than No. The default
setting is 3 seconds.
s "Image file display settings and Slideshow operation settings"
p.55
a
Start PC Free.
The file list screen is displayed.
s
"Starting PC Free" p.51
b
Press the [ ], [ ], [ ], or [ ] buttons to position the cursor
over the folder for the Slideshow that you want to run, and then
press the [
] button.
c
Select Slideshow at the bottom right of the file list screen, and
then press the [
] button.
Slideshow starts, and the image files in the folder are automatically
projected in sequence, one at a time.
When the last file is projected, the file list is displayed again
automatically. If you set Continuous Play to On in the Option
window, projection starts again from the beginning when it reaches
the end.
s "Image file display settings and Slideshow operation settings"
p.55
You can proceed to the next screen, return to the previous screen, or
stop playback while projecting a Slideshow.
a
If Screen Switching Time on the Option screen is set to No, files do
not change automatically when you select Play Slideshow. Press the
[
] button, the [ ] button, or the []] button to continue to the
next file.
You can use the following functions when projecting a file with PC
Free.
Freeze
s "Freezing the Image (Freeze)" p.58
A/V Mute
s "Hiding the Image and Sound Temporarily (A/V Mute)" p.57
E-Zoom
s "Enlarging Part of the Image (E-Zoom)" p.59
Projection Functions
54

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-W28 and is the answer not in the manual?

Epson EB-W28 Specifications

General IconGeneral
Number of colors1.073 billion colors
Native aspect ratio16:10
Projection distance1.68 - 2.02 m
Vertical scan range50 - 85 Hz
Projection technology3LCD
Contrast ratio (typical)10000:1
Screen size compatibility33 - 320 \
Projector native resolutionWXGA (1280x800)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2100 ANSI lumens
FocusManual
Throw ratio1.3 - 1.56:1
Zoom capabilityYes
Focal length range16.9 - 20.28 mm
Aperture range (F-F)1.58 - 1.72
Lamp power200 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)6000 h
Full HDNo
Analog signal format system-
USB connector typeUSB Type-A, USB Type-B
USB 2.0 ports quantity2
Noise level37 dB
Country of originChina
Noise level (economic mode)29 dB
RMS rated power2 W
PlacementDesktop
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.28 W
Power consumption (typical)270 W
Power consumption (PowerSave)201 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 60 %
Cables includedAC, USB
Remote control typeIR
Pallet width800 mm
Pallet height2230 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth234 mm
Width297 mm
Height77 mm
Weight2400 g
Package depth365 mm
Package width360 mm
Package height160 mm
Package weight3980 g
