Epson EB-X51 Service Manual

EB-E01 series Appendix INTERNAL USE ONLY
SEIKO EPSON 179 Revision A
 Error Name/Warning Name/Device ID/Source Name List
*Grey cell is Non-applied ID for this model.
 Error Name
 Warning name
 Device ID name (fan error)
Error Display
Upper layer inner error Inner (RO)
Sensor error Thermistor (SE)
Temperature error Temp (TH)
Fan error Fan (FN)
Lamp error Lamp (PB)
Lamp lit error Lamp On (LF)
Lamp Failure Lamp Off (LF)
Lamp cover open error Cover Open (LC)
RAM H/W error RAM (RA)
ROM H/W error ROM (RO)
12C H/W error I2C (II)
DR inner H/W error DR (ID)
Other H/W error Other HW (RO)
Sub system communication error Sub System (RP)
Sub System error (ROM) Sub System ROM (RS)
Electric capacitor error Capacitor (EC)
Ballast error Ballast (PB)
wind lowered Air (WL)
Wind sensor error Air Sensor (WS)
Exhaust Duct Shutter error Exhaust Shutter (VE)
Auto Iris Error Auto Iris (AI)
Obstruction Detecting error Obstacle (OD)
IF Board discrimination error IF Mismatch (IC)
Stack communication error (SC) Stack (SC)
Stack communication error (SV) Stack Ver (SV)
Ballast mismatch error Ballast Mismatch (BA)
No Lens error Lens Attach (LA)
Lens shift error Lens Shift (LP)
Out of Lens shift range Lens Out (LP)
Cinema filter error Cinema Filter (CF)
Laser error Laser (YE)
Quarts N Polarizer error Laser CPD (AP)
Peltier error Peltier (FE)
Pump error Pump (Fp)
Instability error Voltage (PV)
Portrait Lamp life error P Lamp Life (LL)
Error Display
High Temp Warning Temp (TH)
Warning to replace Lamp Lamp Life (LL)
Easy MP internal error EasyMP (IM)
wind lowered Air (WL)
Filter cleaning Filter Clean (WT)
No filter warning Filter (WN)
Application error
(IML connecting error)
Application (IM)
Pre-obstruction detecting warning Obstacle Pre (OD)
Obstruction Detecting warning Obstacle (OD)
WFD error WFD (WD)
Posture warning Posture (PD)
Setting value warning Set Posture (IS)
Cinema filter warning Cinema Filter (CF)
Laser warning Laser (YE)
ID Display
00 LV0
01 LV1
03 LMP
Error Display

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
