Epson EB-X51 Service Manual

EB-E01 series Appendix INTERNAL USE ONLY
SEIKO EPSON 180 Revision A
 Device ID name (sensor error)
04 PBS
05 EX
06 PBS2
07 EX1
10 POWER
11 LV2
12 LV3
13 LUMI
14 PS
15 PB
16 LMP2
17 PS2
18 EX2
19 PEL
1A LMP3
1B PUMP
1C PEL1
1D PEL2
1E YLD
1F PHW
22 LD1
23 LD2
24 BDM
25 ROUT1
26 ROUT2
27 RIN1
28 RIN2
29 LVR
2A LVG
2B LVB
2C LSM
ID Display
2D EX3
2E PWIN
2F PWOUT
30 LDDR
31 PEL3
32 PEL4
ID Display
00 LV
01 LMP
02 LMA
03 PBS
04 AMIBENT
05 PWR
06 WIND
07 IRIS
08 SCI
09 AIR
0A PB
0B LWR
0C PS2
0D WIHD
0E IM
0F LV2
10 EX
11 YLD
12 PHW
13 BLD
14 YDR
15 BDR
ID Display

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
