Epson EB-X9 User Manual

Using the Remote Control Using the Control panel
q
You can save at 400 ^ 300 dots in size.
E When "Select this image?" is displayed, select "Yes".
F Select the zoom factor from the zoom setting screen.
G When the message "Save this image as the User's Logo?" is
displayed, select "Yes".
The image is saved. After the image has been saved, the message
"Completed." is displayed.
q
• When a User's Logo is saved, the previous User's Logo is erased.
• Saving the user's logo may take approximately 15 seconds. Do not
use the projector or any connected equipment while it is saving,
otherwise malfunctions may occur.
Saving a User's Logo
82

Epson EB-X9 Specifications

General

Matrix size	0.55 \
Projection distance	1.8 - 2.4 m
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	30 °
Audio input	1 x RCA
Aspect ratio	4:3
RS-232 ports	0
Dimensions (WxDxH)	295 x 228 x 77 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
Analog signal format system	-
RMS rated power	1 W
Number of built-in speakers	1
DVI port	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	0.4 W
Power consumption (typical)	265 W
Noise level	37 dB
Country of origin	China
Pallet width	800 mm
Pallet height	2230 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Weight	2300 g
Package depth	360 mm
Package width	340 mm
Package height	160 mm
Package weight	4060 g
