Projector Specifications
148
Product name EHTW650/EHTW610
Dimensions 302 (W) × 87 (H) × 249 (D) mm (not including raised
section)
LCD panel size 0.61"
Display method Poly-silicon TFT active matrix
Resolution 2,073,600 pixels
1080p (1920 (W) × 1080 (H) dots) × 3
Focus adjustment Manual
Zoom adjustment 1-1.2
Lamp UHE lamp, 210 W Model No.: ELPLP96
Lamp life Normal Power Consumption mode: Up to 4,500 hours
ECO Power Consumption mode: Up to 7,500 hours
Max. audio output 2 W
Speaker 1
Power supply 100-240V AC±10% 50/60Hz 3.3 - 1.4 A
Power consumption
(100 to 120 V area)
Operating: 315 W:
Standby power consumption (Communication On): 2.0 W
Standby power consumption (Communication Off): 0.2 W
Power consumption
(220 to 240 V area)
Operating: 298 W:
Standby power consumption (Communication On): 2.0 W
Standby power consumption (Communication Off): 0.2 W
Operating altitude Altitude 0 to 3,000 m
Operating
temperature
+5 to +35°C (No condensation) (Altitude 0 to 2,286 m)
+5 to +30°C (No condensation) (Altitude more than 2,286
m)
Storage temperature -10 to +60°C (No condensation)
Mass Approx. 2.7 kg
This product is also designed for IT power distribution system with phase-to-
phase voltage 230V.
Angle of tilt
If you use the projector tilted at an angle of more than 30˚ it could be
damaged and cause an accident.
gg Related Links
"Connector Specifications" p.148
Connector Specifications
Computer port 1 Mini D-Sub15-pin (female)
Video port 1 RCA pin jack
Audio ports 2 RCA pin jack × 2 (L-R)
HDMI1, HDMI2/MHL ports 2 HDMI (Audio is only supported by
PCM)
USB-A port 1 USB connector (Type A)
USB-B port 1 USB connector (Type B)
a
USB-A and USB-B port supports USB 2.0. However, USB ports are
not guaranteed to operate all devices that support USB.
USB-B port does not support USB 1.1.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EH-TW650 and is the answer not in the manual?

Epson EH-TW650 Specifications

General IconGeneral
Matrix size0.61 \
Number of colors1.073 billion colors
Native aspect ratio16:9
Projection distance1.35 - 1.64 m
Vertical scan range192 - 240 Hz
Projection technology3LCD
Contrast ratio (typical)15000:1
Screen size compatibility30 - 300 \
Projector native resolution1080p (1920x1080)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)1925 ANSI lumens
FocusManual
Throw ratio1.02 - 1.23:1
Focal length range18.2 - 29.2 mm
Aperture range (F-F)1.58 - 1.7
Lamp typeUHE
Lamp power210 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4500 h
Service life of light source (economic mode)7500 h
3DNo
Full HDYes
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity0
Component video (YPbPr/YCbCr) in-
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
Cables includedAC
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.2 W
Power consumption (typical)298 W
Power consumption (economy mode)219 W
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Market positioningHome cinema
Cable lock slot typeKensington
RMS rated power2 W
Pallet width800 mm
Pallet height2204 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth252 mm
Width302 mm
Height92 mm
Weight2700 g
Package depth380 mm
Package width355 mm
Package height160 mm
Package weight3560 g
