Projector Connections
20
e
Connect the other end to the projector's Audio ports.
Connecting to a Computer for USB Video and Audio
If your computer meets the system requirements, you can send video and
audio output to the projector through the computer's USB port. This function
is called USB Display. Connect the projector to your computer using a USB
cable.
a
If you use a USB hub, the connection may not operate correctly.
Connect the USB cable directly to the projector.
a
Connect the cable to your projector's USB-B port.
b
Connect the other end to any available USB port on your computer.
c
Turn on the projector and your computer.
d
Do one of the following to install the Epson USB Display software:
a
You only need to install this software the first time you connect
the projector to the computer.
Windows: Select Run EMP_UDSE.EXE in the dialog box that is
displayed to install the Epson USB Display software.
Mac: The Epson USB Display setup folder is displayed on your
screen. Select USB Display Installer and follow the on-screen
instructions to install the Epson USB Display software. If the USB
Display Setup folder is not displayed automatically, double-click
EPSON_PJ_UD > USB Display Installer.
e
Follow any on-screen instructions.
Do not disconnect the USB cable or turn off the projector until the
projector displays an image.
The projector displays the image from your computer's desktop and outputs
sound if your presentation contains audio.
a
If the projector does not project any images, do one of the following:
Windows: Click All Programs > EPSON Projector > Epson USB
Display > Epson USB Display Ver.x.xx.
Mac: Double-click the USB Display icon in the Application folder.
When you finish projection, do one of the following:
Windows: Disconnect the USB cable. You do not need to operate
Safely Remove Hardware.
Mac: Select Disconnect from the USB Display icon menu on the
menu bar or Dock, and then disconnect the USB cable.
gg Related Links
"USB Display System Requirements" p.150

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EH-TW650 and is the answer not in the manual?

Epson EH-TW650 Specifications

General IconGeneral
Matrix size0.61 \
Number of colors1.073 billion colors
Native aspect ratio16:9
Projection distance1.35 - 1.64 m
Vertical scan range192 - 240 Hz
Projection technology3LCD
Contrast ratio (typical)15000:1
Screen size compatibility30 - 300 \
Projector native resolution1080p (1920x1080)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)1925 ANSI lumens
FocusManual
Throw ratio1.02 - 1.23:1
Focal length range18.2 - 29.2 mm
Aperture range (F-F)1.58 - 1.7
Lamp typeUHE
Lamp power210 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4500 h
Service life of light source (economic mode)7500 h
3DNo
Full HDYes
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity0
Component video (YPbPr/YCbCr) in-
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
Cables includedAC
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.2 W
Power consumption (typical)298 W
Power consumption (economy mode)219 W
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Market positioningHome cinema
Cable lock slot typeKensington
RMS rated power2 W
Pallet width800 mm
Pallet height2204 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth252 mm
Width302 mm
Height92 mm
Weight2700 g
Package depth380 mm
Package width355 mm
Package height160 mm
Package weight3560 g
