Image Quality Settings - Image Menu
94
Settings on the Image menu let you adjust the quality of your image for the
input source you are currently using. The available settings depend on the
currently selected input source.
To change settings for an input source, make sure the source is connected and
select that source.
Setting Options Description
Color Mode See the list of
available color
modes
Adjusts the vividness of image colors for
various image types and environments.
Brightness Varying levels
available
Lightens or darkens the overall image.
Contrast Varying levels
available
Adjusts the difference between light and
dark areas of the image.
Color Saturation Varying levels
available
Adjusts the intensity of the image colors.
Tint Varying levels
available
Adjusts the balance of green to magenta
tones in the image.
Sharpness Varying levels
available
Adjusts the sharpness or softness of
image details.
Setting Options Description
Color Temp. Sets the color tone based on color
temperature. The image is tinted blue
when a high value is selected and tinted
red when a low value is selected.
Color Temp. Color Temp.: sets the color temperature
according to the color mode you selected.
Customized Customized: adjusts the individual R
(red), G (green), and B (blue)
components of the offset and gain.
Enhancement
Adjusts the perceived resolution of the
image:
Noise Reduction Noise Reduction: reduces flickering in
analog images.
Detail
Enhancement
Detail Enhancement: creates a more
emphatic texture and material feel of the
image.
Advanced Selects the various detailed color settings:
Deinterlacing
(For interlaced
signal
[480i/576i/1080i]
input)
Deinterlacing: sets whether or not to
convert interlaced-to-progressive signals
for certain video image types.
Off: for fast-moving video images.
Video: for most video images.
Film/Auto: for movies, computer
graphics, and animation.
Auto Iris Off
Normal
High Speed
Adjusts the projected luminance based
on the image brightness.
Reset Resets all adjustment values on the
Image menu for the selected color mode
to their default settings.
a
The Brightness setting does not affect lamp brightness. To change
the lamp brightness mode, use the Power Consumption setting in
the projector's ECO menu.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EH-TW650 and is the answer not in the manual?

Epson EH-TW650 Specifications

General IconGeneral
Matrix size0.61 \
Number of colors1.073 billion colors
Native aspect ratio16:9
Projection distance1.35 - 1.64 m
Vertical scan range192 - 240 Hz
Projection technology3LCD
Contrast ratio (typical)15000:1
Screen size compatibility30 - 300 \
Projector native resolution1080p (1920x1080)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)1925 ANSI lumens
FocusManual
Throw ratio1.02 - 1.23:1
Focal length range18.2 - 29.2 mm
Aperture range (F-F)1.58 - 1.7
Lamp typeUHE
Lamp power210 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4500 h
Service life of light source (economic mode)7500 h
3DNo
Full HDYes
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity0
Component video (YPbPr/YCbCr) in-
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
Cables includedAC
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.2 W
Power consumption (typical)298 W
Power consumption (economy mode)219 W
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Market positioningHome cinema
Cable lock slot typeKensington
RMS rated power2 W
Pallet width800 mm
Pallet height2204 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth252 mm
Width302 mm
Height92 mm
Weight2700 g
Package depth380 mm
Package width355 mm
Package height160 mm
Package weight3560 g
