Epson EH-TW650 User Manual

Glossary
154
SDTV An abbreviation for Standard Definition Television that refers
to standard television systems which do not satisfy the
conditions for HDTV High-Definition Television.
SNMP An abbreviation for Simple Network Management Protocol,
which is the protocol for monitoring and controlling devices
such as routers and computers connected to a TCP/IP network.
sRGB An international standard for color intervals that was
formulated so that colors that are reproduced by video
equipment can be handled easily by computer operating
systems (OS) and the Internet. If the connected source has an
sRGB mode, set both the projector and the connected signal
source to sRGB.
SSID SSID is identification data for connecting to another device on
a wireless LAN. Wireless communication is possible between
devices with the same SSID.
Subnet Mask This is a numerical value that defines the number of bits used
for the network address on a divided network (subnet) from the
IP address.
SVGA A screen size standard with a resolution of 800 (horizontal) ×
600 (vertical) dots.
SXGA A screen size standard with a resolution of 1,280 (horizontal) ×
1,024 (vertical) dots.
Sync. The signals output from computers have a specific frequency.
If the projector frequency does not match this frequency, the
resulting images are not of a good quality.
The process of matching the phases of these signals (the relative
position of the crests and the troughs in the signal) is called
Synchronization.
If the signals are not synchronized, flickering, blurriness, and
horizontal interference occur.
Tracking The signals output from computers have a specific frequency.
If the projector frequency does not match this frequency, the
resulting images are not of a good quality.
The process of matching the frequency of these signals (the
number of crests in the signal) is called Tracking.
If Tracking is not carried out correctly, wide vertical stripes
appear in the signal.
Trap IP Address This is the IP address for the destination computer used for
error notification in SNMP.
VGA A screen size standard with a resolution of 640 (horizontal) ×
480 (vertical) dots.
XGA A screen size standard with a resolution of 1,024 (horizontal) ×
768 (vertical) dots.
WXGA A screen size standard with a resolution of 1,280 (horizontal) ×
800 (vertical) dots.
WUXGA A screen size standard with a resolution of 1,920 (horizontal) ×
1,200 (vertical) dots.

Epson EH-TW650 Specifications

General

Matrix size	0.61 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	1.35 - 1.64 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	1925 ANSI lumens
Focus	Manual
Throw ratio	1.02 - 1.23:1
Focal length range	18.2 - 29.2 mm
Aperture range (F-F)	1.58 - 1.7
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4500 h
Service life of light source (economic mode)	7500 h
3D	No
Full HD	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Component video (YPbPr/YCbCr) in	-
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	298 W
Power consumption (economy mode)	219 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
RMS rated power	2 W
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	252 mm
Width	302 mm
Height	92 mm
Weight	2700 g
Package depth	380 mm
Package width	355 mm
Package height	160 mm
Package weight	3560 g
