Epson FX-2190IIN Network Guide

Items Settings and Explanation
Access Control Configure a control method for traffic of IP packets.
Permit Access Select this to permit configured IP packets to pass
through.
Refuse Access Select this to refuse configured IP packets to pass
through.
IPsec Select this to permit configured IPsec packets to pass
through.
Local Address(Printer) Select an IPv4 address or IPv6 address that matches your network environment. If an
IP address is assigned automatically, you can select Use auto-obtained IPv4 ad-
dress.
Remote Address(Host) Enter a device's IP address to control access. The IP address must be between 0 and
43 characters. If you do not enter an IP address, all addresses are controlled.
Note:
If an IP address is assigned automatically (e.g. assigned by DHCP), the connection
may be unavailable. Configure a static IP address.
Method of Choosing Port Select a method to specify ports.
Service Name
If you select Service Name for Method of Choosing Port, select an option.
Transport Protocol
If you select Port Number for Method of Choosing Port, you need to configure an
encapsulation mode.
Any Protocol Select this to control all protocol types.
TCP Select this to control data for unicast.
UDP Select this to control data for broadcast and multicast.
ICMPv4 Select this to control ping command.
Local Port
If you select Port Number for Method of Choosing Port and if you select TCP or
UDP for Transport Protocol, enter port numbers to control receiving packets,
separating them with commas. You can enter 10 port numbers at the maximum.
Example: 20,80,119,5220
If you do not enter a port number, all ports are controlled.
Remote Port
If you select Port Number for Method of Choosing Port and if you select TCP or
UDP for Transport Protocol, enter port numbers to control sending packets, sep-
arating them with commas. You can enter 10 port numbers at the maximum.
Example: 25,80,143,5220
If you do not enter a port number, all ports are controlled.
Authentication Method
If you select IPsec for Access Control, select an option.
Pre-Shared Key Enter a pre-shared key between 1 and 127 characters.
Confirm Pre-Shared Key Enter the key you configured for confirmation.
FX-890IIN/FX-2190IIN/FX-2175IIN Network Guide
Security Settings
43

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
