Epson FX-2190IIN Network Guide

Items Settings and Explanation
Encapsulation
If you select IPsec for Access Control, you need to configure an encapsulation
mode.
Transport Mode If you only use the printer on the same LAN, select this.
IP packets of layer 4 or later are encrypted.
Tunnel Mode If you use the printer on the Internet-capable network
such as IPsec-VPN, select this option. The header and
data of the IP packets are encrypted.
Remote Gateway(Tunnel Mode)
If you select Tunnel Mode for Encapsulation, enter a gateway address between 1
and 39 characters.
Security Protocol
If you select IPsec for Access Control, select an option.
ESP Select this to ensure the integrity of an authentication
and data, and encrypt data.
AH Select this to ensure the integrity of an authentication
and data. Even if encrypting data is prohibited, you can
use IPsec.
Related Information
& “Configuring Group Policy” on page 41
& “Combination of Local Address(Printer) and Remote Address(Host) on Group Policy” on page 44
& “References of Service Name on Group Policy” on page 44
Combination of Local Address(Printer) and Remote Address(Host) on Group
Policy
Setting of Local Address(Printer)
IPv4
IPv6*
2
Any addresses*
3
Setting of Remote
Address(Host)
IPv4*
1
✓
-
✓
IPv6*
1
*
2
- ✓✓
Blank
✓✓✓
*1: If IPsec is selected for Access Control, you cannot specify in a prefix length.
*2: If IPsec is selected for Access Control, you can select a link-local address (fe80::) but group policy will be disabled.
*3: Except IPv6 link local addresses.
References of Service Name on Group Policy
Note:
Unavailable services are displayed but cannot be selected.
Service Name Protocol type Local port number Remote port
number
Features controlled
Any - - - All services
FX-890IIN/FX-2190IIN/FX-2175IIN Network Guide
Security Settings
44

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
