GENERAL
The switches set to
the
left are ON, to
the
right are
OFF.
After confirming
that
the
power
cord isdisconnected,
set
the
switches.
SW1
SW2
Fig. 6-7.
Setting
the
DIPSwitches
CAUTION
Do Not use a pencil to
change
switch position. Lead from
the
pencil can
short
the
switch
internally
The
DIP
Switch No. 1 consists of
the
following 8 pins. The functions of
the
respective
DIP
switch pinsand preset conditions are shown intable 6-7.
TABLE
6-7.
Functions
of
DIP
Switch
No. 1 (RX-80/80FT +
/100/100
+)
SW
pin
Function
OFF
ON
Factory-set
Condition
M
Selects
Pica-sized
or
Condensed
mode.
Pica-sized
Condensed
OFF
1-2
Sets
control
codes
(128)o
through (159)oas graphic sym
bols.
Control
code
Graphic symbol
OFF
1-3
Sounds
the
buzzer.
Sounds
Does
not
sounds
OFF
Form
length
11-inch
12-inch
OFF
1-5
Paper-end
detector
Valid
Invalid
OFF
1-6
International
character
set
See
Table
6-8
1-7
International
character
set
See
Table
6-8
1-8
International
character
set
See
Table
6-8
6-8
EPSON
PRINTERS
SW1-1
:This pin allows
the
operator
to select
the
Condensed Print Style
(Power ON position) or
the
Pica-Sized Print Style (Power OFF
position)
when
using
the
printer.
SW1-2:
Graphic symbols corresponding to control codes (128)
through
(159)
are
selected
by
setting
this pin
to
the
ON position.
SWl-3:This pin is used to enable or disable
the
buzzer. When this pin is
at
the
ON position,
the
buzzer will
not
sound. When this pin is
at
the
OFF
position,
the
buzzer will sound. Ifa mechanical error
occurs,
the
buzzer
will
sound
regardless of
the
setting of this pin.
SWl-4:Setting this pin to the
ON
position willset the form length per
page at 12
inches.
The
form
length per page becomes
11
inches
when
this
pin
is
set
to
the
OFF
position.
SWl-5: This pin is used to activate or deactivate
the
paper end detector.
When
the
pin is
turned
ON.
the
paper
end
detection function
becomes invalid
upon
power
application
and
the
printer
is
allowed to operate even ifit isout of paper. Withthe printer in
this state, input of control code
"ESC
9* will permit
the
paper
end
detector
to
be
activated.
SW1-6,SW1-7. SW1-8: Combined use
of
these
three
pins
permits
selection
of
an
international
character
set
(table
6-o).
TABLE
6-8.
International
Character
Set
Designation
Country
SWl-6
SWl-7
SWl-8
USA
ON
ON
ON
FRANCE
ON
ON
OFF
GERMANY
ON
OFF
ON
ENGLAND
ON
OFF
OFF
Country
SWl-6
SWl-7
SW1-8
DENMARK
I
OFF
ON
ON
SWEDEN
OFF
ON
OFF
ITALY
OFF
OFF
ON
SPAIN
OFF
OFF
OFF
