Epson L565 - Printer Basics; Part Names and Functions

Printer Basics
Part Names and Functions
A ADF (Automatic Document Feeder) cover Open when removing jammed originals in the ADF.
B ADF input tray Feeds originals automatically.
C ADF edge guide Feeds originals straight into the printer. Slide to the
edges of the originals.
D ADF output tray Holds originals ejected from the ADF.
A Edge guide Feeds the paper straight into the printer. Slide to the
edges of the paper.
