3.7 User Wires and Pneumatic Tubes
CAUTION
■
Only authorized or certified personnel should be allowed to perform wiring.
Wiring by unauthorized
or uncertified personnel may result in bodily injury and/or
malfunction of the robot system.
User electrical wires and pneumatic tubes are contained in the cable unit.
Electrical Wires
Rated Voltage
Allowable Current
Wires
Nominal Sectional Area
Note
AC/DC30V 1A
15
0.211 mm
2
Twist pair
Unshielded
9
WARNING
■
Do not apply the current more than 1A to the manipulator.
Mfr. Standard
15 pin
Suitable
Connector
JAE
DA-15PF-N (Solder type)
Clamp Hood
DA-C8-J10-F2-1R
(Connector setscrew : #4-40 NC)
9 pin
Suitable
Connector
DE-9PF-N (Solder type)
Clamp Hood
DE-C8-J9-F2-1R
(Connector setscrew : #4-40 NC)
Pins with the same number, indicated on the connectors on both ends of the cables, are
connected.
