110
Options and Consumables
Installing and Using Options
Cut-sheet feeder
The optional single-bin cut-sheet feeder (C80637✽ for
LX-300+II/C80639✽ for LX-1170II) handles up to 50 sheets of
standard bond paper (82 g/m² or 22 lb) without reloading.
Follow these steps to install the cut-sheet feeder:
1. Make sure the printer is turned off. Remove the paper guide
and open the paper guide cover.
2. If the tractor is installed in the pull-tractor position, remove it
and reinstall it in the push-tractor position.
3. Make sure the paper release lever is in the single-sheet
position.
To Next Page
