Feeds continuous paper backwards to the standby position.
6. Pause button
Stops printing temporarily, and resumes printing when pressed again. When pressed for three seconds, turns on the Micro
Adjust mode**. To turn off, press again.
7. Paper Out light
On when no paper is loaded in the selected paper source or when paper is not loaded correctly.
Flashes when paper has not been fully ejected or a paper jam has occurred.
Flashes for three seconds along with the Pause light when the lock-out mode is turned on.
8. Pause light
On when the printer is paused.
Flashes when the printer is in the Micro Adjust mode**.
Flashes when the print head has overheated.
Flashes for three seconds along with the Paper Out light when the lock-out mode is turned on.
Only this light is on in sleep mode. All other lights are off.
* Font select: In the Micro Adjust mode, you can select the font to use for printing by pressing the Tear Off (Font) button.
The font selection lights turn on, off or flash to indicate the selected font.
** Micro Adjust mode: When you hold down the Pause button for three seconds, the printer enters the micro adjust mode. In
this mode, you can press the LF/FF and Load/Eject buttons to adjust the top-of-form or tear-off position. See
Adjusting the top-of-form position.
Top
Selecting a built-in font
Follow these steps to select a built-in font using the buttons on the printer’s control panel:
Make sure that the printer is not printing. If it is, wait until printing is complete.
Hold down the Pause button for three seconds to enter the Micro Adjust mode. The Pause light begins to flash. The two
font selection lights show the current font selection.
Press the Tear Off (Font) button repeatedly to cycle through all of the available selections; then stop when you reach
the desired font with a pattern shown on the control panel. Your selection stays in effect until you change it again.
Note:
Settings you make in your application programs usually override settings you make from the printer’s
control panel. For best results, use your application to select a font and pitch.
Bar code fonts cannot be selected via the control panel.
Top
Panel operations during sleep mode
The printer enters sleep mode if 4 minutes and 30 seconds has passed since the previous operation and no errors have
occurred. The following operations return the printer from sleep mode.
Sending print data.
Pressing a control panel button. Pressing a button once returns the printer from sleep mode and shows the current
status using the control panel lights. To use the normal button functions, press a button one more time.
Note:
Pressing a button only once returns the printer from sleep mode. It returns to sleep mode again if more
than 20 seconds pass without any additional operations being made.

Epson LX-350 Specifications

General

print speed (draft high-speed)	347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)	383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)	260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)	222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)	130 cps (10 cpi)
print speed (near letter quality)	65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width	80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width	3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length	3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness	0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width	3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length	3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness	0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width	6.5" (165 mm)
envelopes (No.6) length	3.6" (92 mm)
envelopes (No.6) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width	9.5" (241 mm)
envelopes (No.10) length	4.1" (105 mm)
envelopes (No.10) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width	4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)	4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness	0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width	8.5" (216 mm)
paper roll holder thickness	0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies	1 original + 4 copies
format space between lines	1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltage	AC 120 V / AC 220 - 240 V
frequency	50 Hz / 60 Hz
power consumption	27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep mode	Approx. 1.1 W
power consumption in powered off mode	0 W
power consumption in auto off mode	Approx. 0.3W
temperature	41 ~ 95°F
humidity	10 ~ 80% RH
mean time before failure	10, 000 POH (at 25% duty)
print head life	400 million strokes/wire
sound level	Approx. 53 dB(A) (ISO 7779 standard)
interfaces	Bidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer	128KB

Weight and Dimensions

width	14.25" (13.7" without knob)
depth	10.83"
height	6.06"
weight	9.04 lb
