Home > Problem Solver
Using the Error Indicators
You can identify many common printer problems using the lights on the control panel. If your printer stops working and one or
more control panel lights are on or flashing or the printer beeps, use the following table to diagnose and fix the problem. If
you cannot fix your problem using this table, see Problems and Solutions.
Panel light state Beep pattern Problem
Solution
Pause
The printer is paused.
Press the Pause button to resume printing.
Paper from another paper source is currently in the paper path.
Move the paper release lever back to the appropriate position
and press the Load/Eject button to clear the paper from the
paper path. Then set the lever to the position you want to use.
Press the Pause button to turn off the Pause light, if
necessary.
Paper Out
Pause
No paper is loaded in the selected paper source.
Load paper in the printer. Then press the Pause button to turn
off the Pause light, if necessary.
The paper is not loaded correctly.
Remove your paper and reload it. See Printing on Continuous
Paper for instructions on loading paper. Then press the Pause
button to turn off the Pause light, if necessary.
Paper is jammed in the printer.
Clear the paper jam as described in Clearing a Paper Jam.
Paper Out
Pause
Continuous paper is not fed back to the standby position.
Tear off the printed document at the perforation; then press the
Load/Eject button. The printer feeds the paper to the standby
position. Press the Pause button to turn off the Pause light, if
necessary.
A single sheet of paper is not fully ejected.
Press the Load/Eject button to eject the sheet. Then press the
Pause button to turn off the Pause light, if necessary.
Paper is jammed in the printer.
Clear the paper jam as described in Clearing a Paper Jam.
Pause
The print head is overheated.
Wait a few minutes; the printer resumes printing automatically
once the print head has cooled.
All the lights on the
control panel
An unknown printer error has occurred.
Turn off the printer and leave it off for several minutes; then
turn on the printer again. If the error recurs, contact your
dealer.
= on, = flashing
= short series of beeps (three beeps)
= long series of beeps (five beeps)
Note:

Table of Contents

Other manuals for Epson LX-350

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson LX-350 and is the answer not in the manual?

Epson LX-350 Specifications

General IconGeneral
print speed (draft high-speed)347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)130 cps (10 cpi)
print speed (near letter quality)65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width6.5" (165 mm)
envelopes (No.6) length3.6" (92 mm)
envelopes (No.6) thickness0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width9.5" (241 mm)
envelopes (No.10) length4.1" (105 mm)
envelopes (No.10) thickness0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width8.5" (216 mm)
paper roll holder thickness0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies1 original + 4 copies
format space between lines1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltageAC 120 V / AC 220 - 240 V
frequency50 Hz / 60 Hz
power consumption27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep modeApprox. 1.1 W
power consumption in powered off mode0 W
power consumption in auto off modeApprox. 0.3W
temperature41 ~ 95°F
humidity10 ~ 80% RH
mean time before failure10, 000 POH (at 25% duty)
print head life400 million strokes/wire
sound levelApprox. 53 dB(A) (ISO 7779 standard)
interfacesBidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer128KB
Weight and Dimensions IconWeight and Dimensions
width14.25" (13.7" without knob)
depth10.83"
height6.06"
weight9.04 lb
