Epson LX-350 User Manual

This setting is available only in the IBM PPDS emulation mode. When auto carriage return is on, each line feed (LF) code or
ESC J code is accompanied by a carriage return code. This moves the print position to the beginning of the next line.
Manual feed wait time
This sets the amount of wait time between the time paper is inserted into the paper guide and when it is fed. If the paper
feeds before you can adjust its position to your satisfaction, you can increase the wait time.
Buzzer (beeper)
The printer beeps when an error occurs or a panel operation is made. (See Using the Error Indicators for more information on
printer errors.) If you do not want the printer to beep, turn off this setting.
Low-noise mode
When you choose On, the noise is reduced, but the printing speed is slower.
IBM character table
This setting is available only in IBM PPDS emulation mode. When you select Table1, hex codes 80H to 90H of the character
tables are used for the control codes. When you select Table 2, hex codes 80H to 90H are used for characters.
Power off timer
When a time is set, the printer automatically turns off after the set time has passed while in standby status. To turn on the
printer again, turn off the power switch and then turn it back on.
Top
Changing default settings
The following table shows the basic function of each button in the default setting mode.
Button Basic function
Menu (LF/FF and Load/Eject) buttons Enters or exits the default setting mode.
Item button
Selects the next menu parameter.
Item button
Selects the previous menu parameter.
Set button Changes the value in the selected menu.
Follow these steps to enter the default-setting mode and change the printer's default settings:
Note:
Before entering the default-setting mode, you need to load A4 or letter size single-sheet paper or
continuous paper that is at least 297 mm (11 inches) long and 210 mm (8.27 inches) wide.
If you use single sheets, you need to load a new sheet of paper each time the printer ejects a printed
sheet.
If you turn off the printer prior to exiting default-setting mode, any changes you may have made are
canceled and not saved.
Make sure paper is loaded.
Press the Menu (LF/FF and Load/Eject) buttons until the printer beep once.

Epson LX-350 Specifications

General

print speed (draft high-speed)	347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)	383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)	260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)	222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)	130 cps (10 cpi)
print speed (near letter quality)	65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width	80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width	3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length	3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness	0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width	3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length	3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness	0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width	6.5" (165 mm)
envelopes (No.6) length	3.6" (92 mm)
envelopes (No.6) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width	9.5" (241 mm)
envelopes (No.10) length	4.1" (105 mm)
envelopes (No.10) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width	4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)	4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness	0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width	8.5" (216 mm)
paper roll holder thickness	0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies	1 original + 4 copies
format space between lines	1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltage	AC 120 V / AC 220 - 240 V
frequency	50 Hz / 60 Hz
power consumption	27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep mode	Approx. 1.1 W
power consumption in powered off mode	0 W
power consumption in auto off mode	Approx. 0.3W
temperature	41 ~ 95°F
humidity	10 ~ 80% RH
mean time before failure	10, 000 POH (at 25% duty)
print head life	400 million strokes/wire
sound level	Approx. 53 dB(A) (ISO 7779 standard)
interfaces	Bidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer	128KB

Weight and Dimensions

width	14.25" (13.7" without knob)
depth	10.83"
height	6.06"
weight	9.04 lb
