Epson LX-350 User Manual

The printer enters the default-setting mode and prints a message prompting you to select the language for the default-
setting menu. The language which is underlined indicates the current setting.
Note:
Depending on the model, language may not be selected.
If the language you want is not selected, press the Item (Tear Off) button until the printout indicates the language
you want.
Note:
You cannot change the language by the Item (LF/FF) button.
Press the Set (Load/Eject) button to select the desired language.
The printer prints a message asking if you wish to print all of the current settings.
Note:
The language you select is also effective when you are entering the lock-out setting mode or bidirectional
adjustment mode.
If you want to print the current settings, press the Set button. If you want to bypass printing of the current settings,
press the Item button or the Item button.
The printer prints the first menu and the current value of the menu.
Press the Item button or the Item button to select the menu parameters which you wish to change. Press the Set
button to scroll through the values within the selected parameter until you find the desired setting. After setting the
selected parameter to the desired setting, you may either continue to make changes to other parameters by pressing the
Item button or the Item button, or exit the default-setting mode by pressing the Menu (LF/FF and Load/Eject)
buttons.
Note:
You cannot change the setting value to the previous item. You have to press the Set button until the value
you want is selected.
When you finish making settings, press the Menu (LF/FF and Load/Eject) buttons.
Release the buttons when all the lights turn on. The printer exits the default-setting mode.
The settings you made is saved as new default value.
Note:
If you turn off the printer prior to exiting default-setting mode, any changes you may have made are
canceled and not saved.
Top

Epson LX-350 Specifications

General

print speed (draft high-speed)	347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)	383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)	260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)	222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)	130 cps (10 cpi)
print speed (near letter quality)	65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width	80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width	3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length	3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness	0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width	3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length	3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness	0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width	6.5" (165 mm)
envelopes (No.6) length	3.6" (92 mm)
envelopes (No.6) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width	9.5" (241 mm)
envelopes (No.10) length	4.1" (105 mm)
envelopes (No.10) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width	4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)	4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness	0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width	8.5" (216 mm)
paper roll holder thickness	0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies	1 original + 4 copies
format space between lines	1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltage	AC 120 V / AC 220 - 240 V
frequency	50 Hz / 60 Hz
power consumption	27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep mode	Approx. 1.1 W
power consumption in powered off mode	0 W
power consumption in auto off mode	Approx. 0.3W
temperature	41 ~ 95°F
humidity	10 ~ 80% RH
mean time before failure	10, 000 POH (at 25% duty)
print head life	400 million strokes/wire
sound level	Approx. 53 dB(A) (ISO 7779 standard)
interfaces	Bidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer	128KB

Weight and Dimensions

width	14.25" (13.7" without knob)
depth	10.83"
height	6.06"
weight	9.04 lb
