C
Align and move the right-side roll core holder
to the right edge of the media.
D
While pressing from the top of the roll core
holder, tighten the fixing screw in place.
E
Insert the roll core onto the right holder.
F
Check that the left-side roll core holder is fully
inserted into the roll core and that the roll core
and edges of the media are not misaligned.
c
Important:
If the edges of the media are misaligned, the
media cannot be taken up correctly. If the
edges are misaligned, loosen the fixing screw
for the right-side roll core holder, and then
restart from step 3.
