17
The LCD Screen
1 Displays the network connection status
2 Press an arrow button to scroll left or right
3 Menu options
4 Displays available button actions
Parent topic: Control Panel Buttons and Lights
Status Icon Information
Your product displays status icons on the LCD screen for certain product status conditions.
Icons Description
The product is not connected to a wireless network.
The product is searching for an SSID or experiencing a wireless network connection issue.
The product is connected to a wireless network. The number of bars indicates the
connection's signal strength.
Wi-Fi Direct is not enabled.
Wi-Fi Direct is enabled.
Parent topic: Control Panel Buttons and Lights
