Setup and Maintenance
90
Checking with Detect Clogging
The printer checks the status of the nozzles, and displays any clogged nozzles on the screen. Perform Print Head
Unit cleaning according to the check results.
A
Click Detect Clogging.
Clogging detection starts, and the status of each nozzle is indicated by the colors.
Clogging detection takes about one minute.
Reading the Results:
Tip:
The method for confirming the status of the nozzles also includes the method for printing a check pattern.
U “Printing the check pattern” on page 92
Color Explanation
Green The nozzles are not clogged.
Yellow Clogging is detected.
Perform Normal cleaning.
Red Clogging is detected.
Perform Powerful cleaning.
Gray Head cleaning is complete.
White Detect Clogging is still in progress.
