Version 3.00 Feb. 2019
2
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-H6000III)
Section 2. Details on Settings
This section describes connection configurations and how to make the settings for the
TM-H6000III printer.
2.1 References of Firmware Versions
Please refer to the release notes (Relnote.txt).
2.2 Settings of DIP Switches
Confirm that the following settings have been made correctly.
1) Serial port
DIP-SW1 DIP-SW2
No. Setting
No. Setting
1 OFF Recommended 1 OFF Settable
2 OFF Recommended 2 OFF Settable
3 OFF Fixed at OFF 3 OFF Settable
4 OFF Fixed at OFF 4 OFF Settable
5 OFF Settable 5 OFF Fixed at OFF
6 OFF Settable 6 OFF Fixed at OFF
7 ON Settable 7 OFF Fixed at OFF
8 OFF Settable 8 OFF Fixed at OFF
It is possible to change the settings of DIP-SW1-1 and DIP-SW1-2, but it is
recommended to leave them OFF.
Set DIP-SW1-3 (Handshake) to DTR/DSR.
Set DIP-SW1-4 (Bit length) to 8 bits.
Set DIP-SW1-5 to DIP-SW1-8 accordance with the port information.
The described set values are the default values. For the details, please refer to
the product manual of the POSPrinter. Also, if these settings are changed, make
sure to change the port information using the SetupPOS utility.
Set DIP-SW2-2 in accordance with whether or not a customer display is
connected.
If connected, set to ON. If not, set to OFF.
To Next Page
