APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-H6000III)
Do not change the current settings of DIP-SW2-5 to DIP-SW2-8.
Make other settings in accordance with the settings described above.
4) Ethernet Port
DIP-SW1 DIP-SW2
No. Setting No. Setting
1 OFF Recommended 1 OFF Settable
2 OFF Recommended 2 OFF Fixed at OFF
3 OFF Fixed at OFF 3 OFF Settable
4 OFF Fixed at OFF 4 OFF Settable
5 OFF Fixed at OFF 5 OFF Fixed at OFF
6 OFF Fixed at OFF 6 OFF Fixed at OFF
7 OFF Fixed at OFF 7 OFF Fixed at OFF
8 OFF Fixed at OFF 8 ON Fixed at ON
It is possible to change the settings of DIP-SW1-1 and DIP-SW1-2, but it is
recommended to leave them OFF.
Set DIP-SW2-3 and DIP-SW2-4 to match the environment of use.
Do not change the current settings of DIP-SW2-5 to DIP-SW2-8.
Make other settings in accordance with the settings described above.
2.3 Port Information
1) Port information w
hen serial port is used
The port information that can be set with the SetupPOS utility is as follows.
Item Setting range
Baud rate [bps] 4800, 9600, 19200, 38400
Bit length [bit] 8
Parity NONE, ODD, EVEN
Stop bit [bit] 1
Handshake DTR/DSR
Output buffer length [byte] 32 to 1024
Output interval time [ms] 0 to 9999
To Next Page
