Connectors
All connectors are located on the lower rear of the printer.
1 Serial interface connector
For connecting a serial cable for connecting to a computer.
2 USB Plus Power connector
For connecting a USB Plus Power cable for connecting to a computer.
3 DM-D connector
For connecting the customer display.
4 Drawer kick connector
For connecting a modular cable for the cash drawer.
5 USB connector
For connecting an Epson certified unit.
6 Ethernet connector
For connecting a LAN cable.
7 Power supply connector
For connecting the power cable.
8 USB connector (type-B)
For connecting a USB cable for connecting to a computer.
