120
Appendix
*1: Installed character codes vary by printer model.
*2: Only the character sets installed on the printer can be printed.
*3: Space between characters is not included. Characters can be scaled up to 64 times as large as the standard size.
Character size is the same in both 48/35 column mode and 42/32 column mode.
Character size
*3
(W × H)
Font A 1.25 × 3.00 mm {0.05 × 0.12"}
Font B 1.13 × 3.00 mm {0.04 × 0.12"}
Font C 0.88 × 2.13 mm {0.03 × 0.08"}
Special Font A 1.25 × 3.0 mm {0.05 × 0.12"}
Special Font B 0.88 × 3.0 mm {0.03 × 0.12"}
Kanji Font A 3.00 × 3.00 mm {0.12 × 0.12"}
Kanji Font B Japanese: 2.26 × 3.00 mm {0.09 × 0.12"}
Korean: 2.00 × 2.00 mm {0.08 × 0.08"}
By specifying UTF-8 character encoding, all the installed character sets can be printed.
For more details on printing Unicode characters, see "FS ( C" of the ESC/POS command reference, or
manual of the software you use. ("Application Development Information" on page 93)
