Chapter 2 Setup

Passing Cables through the Bottom

If the desk or table on which the printer is to be installed has a hole through which cables can pass, it is best to

pass the cables through the slot in the bottom of the printer.

Rear cover

Slot in the bottom of the printer

Bottom cover
