Epson TM-T70 II User Manual

30
Buzzer Setting
Select the [Buzzer Setting] tab.
Whether or not the buzzer is used, the buzzer pattern, and the number of times the buzzer sounds
can be set.
Setting Description
Buzzer Not used (Default) Does not sound the buzzer.
Sound before printing Sounds the buzzer before printing.
Sound after printing Sounds the buzzer after printing.
Sound Pattern Internal buzzer (Default) Sounds an internal buzzer.
Option Buzzer (Pattern A to E) Sounds an external buzzer.
The buzzer pattern can be selected
from five patterns; A to E.
Buzzer Repeat 1, 2, 3, 5
(Default:1)
Specifies the number of times the
buzzer sounds.

Epson TM-T70 II Specifications

General

Print Method	Thermal line printing
Print Speed	250 mm/sec
Weight	1.8 kg
Auto Cutter	Yes
Paper Roll Diameter	83 mm
Paper Width	79.5 ±0.5 mm
Interface	USB, Serial, Ethernet
Dimensions	125‎ x 194 x 114 mm (Width x Depth x Height)
Operating Temperature	5 to 45 °C
Operating Humidity	10 - 90%
