Epson TM T88V User Manual

104
Exception handling
A command transmission/reception API generates a propriety exception with an integer (int) type
parameter when an error occurs and notify the calling side of such an error.
Steps for Handling
Use the EpsonIoException class's getStatus (p.99) to get the error value. Please refer to the following code.
List of Error Values
Error values are defined in the IoStatus class.
Error Value Cause
IoStatus.ERR_PARAM
Invalid parameter was passed.
<Example>
 An invalid parameter such as null was passed.
 A value outside the supported range was specified.
IoStatus.ERR_OPEN Open processing failed.
IoStatus.ERR_CONNECT
Failed to connect to device.
<Example>
 Failed to send data to the target device for a reason other than
a timeout.
 Failed to receive data from the target device for a reason other
than a timeout.
IoStatus.ERR_MEMORY Could not allocate the necessary memory for processing.
IoStatus.ERR_ILLEGAL
Illegal method used.
<Example>
 The API for sending and receiving data was called when the
device port was not open.
 The printer search API was called again when a printer search
was already in progress.
IoStatus.ERR_PROCESSING
Could not execute process.
<Example>
Could not get lock rights to the shared resource because the
same process is currently being executed by another thread.
IoStatus.ERR_FAILURE An unspecified error occurred.
String str = "Hello, World!\r\n";
byte[] data = str.getBytes();
int offset = 0;
int size = data.length;
int timeout = 5000;
int sizeWritten = 0;
int errStatus = IoStatus.SUCCESS;
try {
sizeWritten = mPort.write(data, offset, size, timeout);
} catch ( EpsonIoException e ) {
//Get error value
errStatus = e.getStatus();
}

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
