Epson TM T88V User Manual

91
Chapter 4 API Reference
4
sendData
Sends a print document created using the Builder class.
Syntax
public void sendData(Builder builder, int timeout
, int[] status) throws EposException
Parameter
 builder : Specifies a Builder class instance. For details on the Builder class, refer to Builder class
(p.39).
 timeout : Specifies the transmission/reception waiting timeout time. 
Specifies an integer in the range 0-600000 (in milliseconds).
 status : The printer status when command transmission ended is set. A combination of printer
status settings is set. For details, refer to Printer Status List (p.37).
Exceptions
When processing fails, EposException is thrown with one of the following error values.
• If you are using a Bluetooth connection, it may not be able to detect the offline status,
and timeout errors may occur.
• If you are using a Bluetooth connection, it may not be able to detect that the printer's
power is off.
In an exception occurs, use the getPrinterStatus (p.94) with exception processing to get the
printer status.
Error status Description
ERR_PARAM Invalid parameter was passed.
ERR_ILLEGAL This API was called when communication had not started yet.
ERR_PROCESSING Could not execute process.
ERR_TIMEOUT Could not send all the data within the specified time.
ERR_CONNECT Connection error occurred
ERR_MEMORY Could not allocate memory.
ERR_OFF_LINE The printer was offline.
ERR_FAILURE An unspecified error occurred.

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
