78
addPageLine
Adds line drawing in page mode to the command buffer. Draws a line in page mode.
Syntax
public void addPageLine
(int x1, int y1, int x2, int y2, int style)
throws EposException
Parameter
x1: Specifies the horizontal start position of the line (in dots).
Specifies an integer from 0 to 65535.
y1: Specifies the vertical start position of the line (in dots).
Specifies an integer from 0 to 65535.
x2 : Specifies the horizontal end position of the line (in dots).
Specifies an integer from 0 to 65535.
y2 : Specifies the vertical end position of the line (in dots).
Specifies an integer from 0 to 65535.
style : Specifies the line type.
Exceptions
When processing fails, EposException is thrown with one of the following error values.
Diagonal lines cannot be drawn.
Use this API function by inserting it between addPageBegin (p.70) and addPageEnd (p.71).
Set value Description
Builder.LINE_THIN Solid line: Thin
Builder.LINE_MEDIUM Solid line: Medium
Builder.LINE_THICK Solid line: Thick
Builder.LINE_THIN_DOUBLE Double line: Thin
Builder.LINE_MEDIUM_DOUBLE Double line: Medium
Builder.LINE_THICK_DOUBLE Double line: Thick
Builder.PARAM_DEFAULT Solid line: Thin
Error status Description
ERR_PARAM Invalid parameter was passed.
ERR_MEMORY Could not allocate memory.
ERR_FAILURE An unspecified error occurred.

Table of Contents

Other manuals for Epson TM T88V

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson TM T88V and is the answer not in the manual?

Epson TM T88V Specifications

General IconGeneral
Dimensions (WxDxH)145 x 195 x 148 mm
USB portYes
Standard interfacesRS-232, USB 2.0
Serial interface typeRS-232
Serial ports quantity1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technologyWired
TypePOS printer
Print speed11.8 ips
Print technologyThermal
Maximum resolution180 x 180 DPI
SafetyUL1950/CSA C22.2 No. 950
CertificationFCC/ICES-003
Built-in barcodes2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of originChina
Autocutter durability2 million cuts
Mean time between failures (MTBF)360000 h
Product colorBlack
Maximum roll diameter83 mm
Supported paper width80, 58 mm
Printing media thickness55 - 80 µm
Storage temperature (T-T)-10 - 50 °C
Operating temperature (T-T)5 - 45 °C
Operating relative humidity (H-H)10 - 90 %
Ethernet LANNo
Input current1.8 A
Power supply typeDC
Pallet width800 mm
Pallet height2550 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pallet128 pc(s)
Quantity per pallet (UK)192 pc(s)
Master (outer) case width400 mm
Quantity per pallet layer16 pc(s)
Master (outer) case height255 mm
Master (outer) case length490 mm
Quantity per pallet layer (UK)24 pc(s)
Quantity per master (outer) case4 pc(s)
Package depth257 mm
Package width193 mm
Package height241 mm
Package weight2660 g
Quantity per pack1 pc(s)
