Epson TM T88V User Manual

72
addPageArea
Adds the print area in page mode to the command buffer.
Specifies the print area in page mode (coordinates). After this API function, specify a print data API function
such as the addText method.
Syntax
public void addPageArea(int x, int y, int width
, int height) throws EposException
Parameter
 x : Specifies the origin of the horizontal axis (in dots). Specifies an integer from 0 to 65535. 0
is the left end of the printer's printable area.
 y : Specifies the origin of the vertical axis (in dots). Specifies an integer from 0 to 65535. 0 is
the position in which no paper feed has been performed.
 width : Specifies the width of the print area (in dots). Specifies an integer from 0 to 65535.
 height : Specifies the height of the print area (in dots). Specifies an integer from 0 to 65535.
Exceptions
When processing fails, EposException is thrown with one of the following error values.
Specify a print area to cover the content to be printed. If the print data extends beyond the print
area, the print result will be such that the print data has been printed incompletely.
Use this API function by inserting it between addPageBegin (p.70) and addPageEnd (p.71).
Determine the width and height of the print area according to the print direction setting. Otherwise,
the print data might not be printed completely.
Error status Description
ERR_PARAM Invalid parameter was passed.
ERR_MEMORY Could not allocate memory.
ERR_FAILURE An unspecified error occurred.

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
