Epson TM T88V User Manual

83
Chapter 4 API Reference
4
addPulse
Adds the drawer kick to the command buffer. Sets the drawer kick.
Syntax
public void addPulse(int drawer, int time)
throws EposException
Parameter
 drawer : Specifies the drawer kick connector.
 time : Specifies the ON time of the drawer kick signal.
Exceptions
When processing fails, EposException is thrown with one of the following error values.
Example
• Not available in page mode.
• The drawer and the buzzer cannot be used together.
Set value Description
Builder.DRAWER_1 Pin 2 of the drawer kick-out connector
Builder.DRAWER_2 Pin 5 of the drawer kick-out connector
Builder.PARAM_DEFAULT Pin 2 of the drawer kick-out connector
Set value Description
Builder.PULSE_100 100 ms
Builder.PULSE_200 200 ms
Builder.PULSE_300 300 ms
Builder.PULSE_400 400 ms
Builder.PULSE_500 500 ms
Builder.PARAM_DEFAULT 100 ms
Error status Description
ERR_PARAM Invalid parameter was passed.
ERR_MEMORY Could not allocate memory.
ERR_FAILURE An unspecified error occurred.
To send a 100msec pulse signal to the pin 2 of the drawer kick connector:
try {
Builder builder = new Builder("TM-T88V", Builder.MODEL_ANK);
builder.addPulse(Builder.DRAWER_1, Builder.PULSE_100);
///Process///
} catch (EposException e) {
int errStatus = e.getErrorStatus();
}

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
