Epson TM T88V User Manual

62
To specify binary data that cannot be represented by character strings, use the
following escape sequences.
 type : Specifies the barcode type.
 hri : Specifies the HRI position.
BARCODE_GS1_
DATABAR_EXPANDED
You can enclose an application identifier (AI) in
parentheses. The parentheses are used as HRI print
characters and are not encoded as data.
To encode each of the following characters, specify two
characters starting with the character "{":
FNC1: {1
(: {(
): {)
String Description
\xnn Control code
\\ Back slash
Set value Barcode type
Builder.BARCODE_UPC_A UPC-A
Builder.BARCODE_UPC_E UPC-E
Builder.BARCODE_EAN13 EAN13
Builder.BARCODE_JAN13 JAN13
Builder.BARCODE_EAN8 EAN8
Builder.BARCODE_JAN8 JAN8
Builder.BARCODE_CODE39 CODE39
Builder.BARCODE_ITF ITF
Builder.BARCODE_CODABAR CODABAR
Builder.BARCODE_CODE93 CODE93
Builder.BARCODE_CODE128 CODE128
Builder.BARCODE_GS1_128 GS1-128
Builder.BARCODE_GS1_DATABAR_OMNIDIRECTIONAL GS1 DataBar Omnidirectional
Builder.BARCODE_GS1_DATABAR_TRUNCATED GS1 DataBar Truncated
Builder.BARCODE_GS1_DATABAR_LIMITED GS1 DataBar Limited
Builder.BARCODE_GS1_DATABAR_EXPANDED GS1 Databar Expanded
Set value Description
Builder.HRI_NONE(default) HRI not printed
Builder.HRI_ABOVE Above the bar code
Builder.HRI_BELOW Below the bar code
Builder.HRI_BOTH Both above and below the bar code
Builder.PARAM_UNSPECIFIED Retains the current setting.
Barcode type Description

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
