Epson TM T88V User Manual

68
 level : Specifies the error correction level.
 width : Specifies the module width.
 height : Specifies the module height.
Set value Description
Builder.LEVEL_0 PDF417 error correction level 0
Builder.LEVEL_1 PDF417 error correction level 1
Builder.LEVEL_2 PDF417 error correction level 2
Builder.LEVEL_3 PDF417 error correction level 3
Builder.LEVEL_4 PDF417 error correction level 4
Builder.LEVEL_5 PDF417 error correction level 5
Builder.LEVEL_6 PDF417 error correction level 6
Builder.LEVEL_7 PDF417 error correction level 7
Builder.LEVEL_8 PDF417 error correction level 8
Builder.LEVEL_L QR Code error correction level L
Builder.LEVEL_M QR Code error correction level M
Builder.LEVEL_Q QR Code error correction level Q
Builder.LEVEL_H QR Code error correction level H
Builder.LEVEL_DEFAULT Default level
Builder.PARAM_UNSPECIFIED Retains the current setting.
• Select the level according to the 2D-Code type.
• For MaxiCode and two-dimensional GS1 DataBar, select Builder.LEVEL_DEFAULT.
Set value Description
Integer from 0 to 255 Module width
Builder.PARAM_UNSPECIFIED Retains the current setting.
MaxiCode is ignored.
Set value Description
Integer from 0 to 255 Module height
Builder.PARAM_UNSPECIFIED Retains the current setting.
QR Code/MaxiCode/two-dimensional GS1 DataBar are ignored.

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
