Printer Basics
Part Names and Functions
Front/Right side
A
Control panel Allows you to make settings and perform operations on the printer.
Also displays the printer’s status.
B
ADF cover (F) Open when paper is jammed in the ADF (Automatic Document
Feeder).
C
ADF (Automatic Document Feeder) Device that automatically loads documents.
D
Face down tray Holds the print outs.
E
MP tray Loads the paper. You can load all types of paper (thick paper and
envelopes) that can be used in this printer.
F
Cover (J) Open when paper is jammed.
G
Cover (E) Open when paper is jammed.
H
Paper cassette 1, 2, 3, 4 (C1, C2, C3, C4) Loads the paper.
User's Guide
Printer Basics
13
To Next Page
