Product description
Part index
The index below refers to Fig. 1 on page 4.
1. Main handles
2. Scale wheel
3. Adjustment knob
4. Standing feet
5. Air vents
6. Speed dial
7. Depth stop
a. Scale
8. Fixing screw for depth stop
9. Parallel guide assembly
a. Guide base assembly
b.
c. Hole for centre pin
d.
e. Adjustment guide assembly
f. Scale wheel
g. Fine adjustment knob
h. Guide rods
10. Step buffer
11. Base plate
12. Vacuum cleaner adaptor
13.
14. Spindle lock
15. On/off switch
16. Lock-off button
17. Scale
18. Indicator
19. Fixing lever
(for cutting depth adjustment)
20. Clamp nut with collet
(1/2” for UK; 12mm for EU)
21. Centre pin
a. Screw
b. Washer
c. Pin
22. Router bit
a. Straight bit
b. Core box bit
c. V groove bit
23. Collet
(1/4” and 3/8” for UK; 6 and 8mm
for other countries)
24. Screws for template guide
25. Template guide (16 mm)
26. Template guide (30 mm)
27. Wrench
others the following symbols and abbreviations. Familiarize yourself with them to
reduce hazards like personal injuries and damage to propert
