WARNING! Danger of kickback! Apply the product to the workpiece only
when switched on!
WARNING! Always ensure the base plate lays at on the workpiece
during operation! Do not try to make cuts with the product only held by
one hand!
02
Direction of feeding (Fig. N and O)
Always route against the rotation direction of the router bit. Otherwise the router bit will
become loose in the collet and the router will be difcult to control because the kick-
back and guiding force are in same direction (Fig. N).
Move the product anticlockwise when routing on workpiece edges, move the product
clockwise when routing the inside of the workpiece (Fig. O).
NOTE: For satisfactory results we recommend always using the guides
provided.
03
Parallel cuts and edging
Parallel cuts and edging shall use the parallel guide assembly (9) provided.
1. Set the cutting depth rst.
2. Attach the parallel guide assembly (9) to the product.
3. Place the product on the workpiece with the parallel guide assembly (9) laying
against the workpiece edge and adjust it to the desired width.
4. Fasten all the xing elements parallel guide assembly (9) tightly and check them
regularly during working period.
5. Guide the router with light leaning force to the work piece edge.
04
Circles
1. Set the cutting depth carefully.
2. Attach the centre pin (21) to the parallel guide assembly.
3. Set the desired circle radius by adjusting insertion of the guide rods (9h x2).
4. Mark the centre of the circle and slightly punch the pin into it. Make sure it cannot
slip out during operation to achieve a satisfying result.
5. Start routing around the centre of the circle.
Pre-drilling of a hole which has same diameter of the tip of the centre pin
(21) will be helpful to keep the centre pin (21) in position.
05
Template cuts (Fig. P)
1. Attach the suitable template guide (25 or 26) to the product.
2. Lay the template onto the workpiece and x it using proper clamps. Fix the clamps
in a way that they will not block the movement of the product.
3. Place the product on the workpiece with the collar of the template guide lying
against the template edge.
4. Apply light pressure against the template during operation to ensure the template
guide lies at against the template edge.
WARNING! Only use router bits which are smaller than the centre
opening of the template guide.
The template must have a minimum thickness of 8 mm due to the
protruding template guide.
• Consider about dislocation of the routing channel/edge to template.
• Adjustment of cutting depth shall consider the thickness of template.
After use
1. Switch the product off, wait for complete stop, disconnect it from the power supply,
let it cool down and remove the router bit.
2. Check, clean and store the product as described below.
