33
Pre-drilling of a hole which has same diameter of the tip of the centre pin
(21) will be helpful to keep the centre pin (21) in position.
05
Template cuts (Fig. P)
1. Attach the suitable template guide (25 or 26) to the product.
2. Lay the template onto the workpiece and x it using proper clamps. Fix the clamps
in a way that they will not block the movement of the product.
3. Place the product on the workpiece with the collar of the template guide lying
against the template edge.
4. Apply light pressure against the template during operation to ensure the template
guide lies at against the template edge.
WARNING! Only use router bits which are smaller than the centre
opening of the template guide.
The template must have a minimum thickness of 8 mm due to the
protruding template guide.
• Consider about dislocation of the routing channel/edge to template.
• Adjustment of cutting depth shall consider the thickness of template.
After use
1. Switch the product off, wait for complete stop, disconnect it from the power supply,
let it cool down and remove the router bit.
2. Check, clean and store the product as described below.
2100W router MNL_ER2100_TPS_GB_V02_20180608.indd 33 6/8/18 19:22
