25
Centre pin (Fig. B, C, D, E)
Use the centre pin (21) to cut circles, arcs or circular pattern into the workpiece.
1. Loosen the adjustment guide xing knobs (9d x2) anticlockwise (Fig. B, step 1).
2. Loosen the guide base xing knobs (9b x2) anticlockwise (Fig. B, step 2).
3. Remove the guide rods (9h x2) and keep the springs safe.
4. Loosen ne adjustment knob (9f) completely and remove it (Fig. B, step 3).
5. Assemble the centre pin (21) on the adjustment guide assembly (9e) and tighten
the screw (21a) (Fig. D, step 1).
6. Insert the guide rods (9h x2) into the inner mounting holes of the adjustment guide
assembly (9e) (Fig. D, step 2) and tighten the adjustment guide xing knobs (9d
x2) (Fig. D, step 3).
7. Loosen the parallel guide xing knobs (13) anticlockwise (Fig. E, step 1).
8. Align the adjustment guide assembly (9e) with centre pin (21) and guide rods (9h
x2) to the mounting holes of the base plate (11) and insert it (Fig. E, step 2).
9. Slide the adjustment guide assembly (9e) with centre pin (21) and guide rods (9h
x2) in the rail of the base plate (11) to adjust to adjust the desired cutting radius “R”
which is determined by the distance between the tip of centre pin and the routing
axis (Fig. E).
WARNING! To ensure the safety and quality of the application with centre
pin (21), the two guide rods (9h x2) shall be inserted into the base plate
(11) sufciently until the tips come out from the other side of the base
plate.
10. Fix the adjustment guide assembly (9e) with centre pin (21) and guide rods (9h x2)
in position by tightening the parallel guide xing knobs (13) clockwise (Fig. E, step
3).
Detaching
1. Loosen the parallel guide xing knobs (13) anticlockwise (Fig. C, step 1).
2. Remove the parallel guide assembly (9) off the base plate (11).
3. Tighten the parallel guide xing knobs (13) clockwise.
04
Template guide (Fig. F)
Use the template guides (25 or 26) for template routing on workpiece.
2100W router MNL_ER2100_TPS_GB_V02_20180608.indd 25 6/8/18 19:22
