TC-32
1
IMPORTANT: Before starting with the installation, you should read this operation handbook carefully.
STEPS TO FOLLOW
•
Machine handling and transport
•
Machine start-up.
•
Operation and adjustment.
• Most important maintenance and repairs operations.
DESCRIPTION OF THE ABOVE STEPS
• MACHINE HANDLING AND TRANSPORT
Machine handling from floor-transport-floor or another transport, is carried out with suitable cranes
and lifting auxiliary items, which must assure enough loading capacity to lift the load safely.
This handbook also shows how the handling operations must be performed (see page 17).
• MACHINE START-UP.
The machine should be installed in a place, which is protected against inclement weather. The
foundation should have enough capacity to support the weight of the machine and it should also be
tough enough to support the machine without inadmissible deformations, which prevent the correct
function of the machine. Besides you should avoid the transmission of any vibration to the floor or
structure of the place.
You should provide enough room around the machine to ease the operation, handling of materials,
machine maintenance and staff safety.
Before the start up of the machine, please note the following:
• Skilled workers, equipped with the correct clothing and tools should carry out the start-up.
•
Make sure that the machine has enough space with or without auxiliary tables to allow and ease
the safe, working, maintenance and repair operations.
•
Ensure that the machine foundation and vibration proof system is adequate (page 9)
•
Check the supply voltage.
•
Make sure that the current to be used is the same as the drilling voltage.
•
The main switch nº1 (page 4) is installed in the electric cabinet, as per drawing nº3 (page 4). - On
machines with three phase connection, the connection should be EARTH, RST and if required N
(N= Neutral).
•
Before checking the turning sense, make sure that the automatic feed command and/or the
sensitive feed are disconnected. See point 7 (page 2).
•
Test that the main spindle and the coolant pump (if it has) is running in the correct direction, as
per indicated on the command plate.
•
In the machines supplied with pneumatic or hydraulic equipment, regulate the rate of airflow and
the required minimum pressure as per the operation handbook.
• OPERATION AND ADJUSTMENT
1. TOOL SETTING
Always make sure that the machine is stopped. Grip the spindle downward command with the
right hand and with the left-hand insert the tool into the spindle taper with a dead blow. Take into
account that the tool releasing tongue and the shaft housing are in the correct position. As per
drawing nº2 (page 4)
2. TABLE HEIGHT ADJUSTMENT AND SUPPORT UNIT TURNING
Unlock the locking command nº10 (page 9) of the support and with vertical displacement
command of the support nº14 (page 9), adjust the table height. Lock again the locking command
nº10 (page 9) of the support.
3. TABLE SUPPORT INCLINATION ADJUSTMENT
