TC-32
3
DRILLING.
•
All the pieces to be machined as well as the holding items should always be well secured to the
working table.
•
All the support, table and column locking commands should always is well locked.
• The danger indicating plates should always be taken into account.
• The command of the automatic tool ejector device should always be in "A" position as per
drawing nº
• 2 and 3 (page 4)
• Do not work in automatic feed, while command nº3 is in "B" position, as per nº2 and 3 (page 4).
•
Take special care, while working in manual or automatic feed, with command nº9 (page 9) when
it returns, due to the elastic energy of the return spring of the main spindle.
REPAIR AND MAINTENANCE
All the repair and maintenance operations, must be carried out by skilled staff and taking the
necessary safety measures.
•
COOLANT TANK
The base of the drilling machine is used as a coolant tank, with a capacity of:
TC.32 / TC.35 10 litres
