28
The display will show the following:
By the numerical keyboard, set the desired final scale value (For
Example 2 it is equal to 20.000 mA).
Push the FUNC push-button.
By the numerical keyboard, set the desired read-out assigned to
the final scale value (For Example 2 it is equal to 200.00 (m
3
/h).
Push the FUNC push-button.
NOTES:
1) For the read-out in eng. units, the number of decimal figures will
be equal to the decimal figure programmed in "L.RNG EU".
2) For the read-out in eng. units, the number of decimal figures is
free with respect of the read-out limits (20000 counts).
The instrument will start to measure and, for Example 2, if a 7 mA
signal is applied to the input terminal the display will show:
NOTES:
1) The instrument will automatically select the input range contain-
ing the two programmed values ("L.RANGE mA" and "H.RANGE
mA") with the maximum resolution.
2) During mA measurement with programmable read-out scaling it is
possible to enable/disable, by the REV/MOD push-button, the
scaling function and to display the measured value in mA.
3) During mA measurement, the instrument is able to measure and
display up to 5 % more than the upper programmed value or 5%
less than the lower programmed value.
H.RNG XXXXXX mA
H.RNG XXXXXX EU
MEAS RNG( )mA
86.71 EU
M20-e-3.p65 7/9/01, 2:40 PM28
