4.2 -HOW TO MODIFY A ROUTINE.
Depress the PROG push-button; the display will show the following:
Where:
YY indicates how many program steps are still available.
XX enter in this field the identification code number of the routine
to be created, edited or run.
When it is desired to know the identification code already utilized,
depress s or t push-buttons. On the lower display line will appear
the ID. code already in existence.
If the lower line is completely filled, depress s or t push-button
again to scroll the remaining codes.
Type the ID. code of the routine to be modified and push the FUNC
push-button.
The display will show the following:
Where:
RUN enables the sequential function routine execution;
EDIT enables the EDIT mode of the selected routine;
DEL delete the selected routine.
When it is desired to delete the selected routine, select the DEL option
and push the FUNC push-button.
The display will show the following:
Select YES and depress FUNC push-button. The instrument
deletes the selected routine and returns automatically to the
STAND BY mode.
By selecting NO the instrument returns to the previous menu.
When it is desired to modify the program, select EDIT and then
depress FUNC push-button.
The display will show the following:
The display shows the first step parameters.
Four different situations may occur:
A) The first program step is correct.
PROGRAM N XX
YY FREE STEP(S)
PROGRAM N XX
1 3 5 7 12 15
PROGRAM N 15
RUN EDIT DEL
PROG XX DELETE?
NO YES
OUT J E 25.5
150 °C 01
