58
SECTION 4 SEQUENTIAL FUNCTION ROUTINES
a) If the selected routine does not exist, the instrument will switch
automatically to the EDIT mode.
b) If the selected routine exists, the display will show:
In this case referred to the paragraph "2- how to modify a routine".
The display will show the following:
Where :
15 shows the identification code of the selected sequence
01 is the step number you are editing.
MEASallows to insert a measurement step.
OUT allows to insert a generation step.
SBY allows to insert a "Stand-by" step.
STO allows to store, in the present step, the parameters of the
"action" inserted prior to the editing of the sequential function
routine.
NOTES:
A) When MEAS is selected, the instrument will execute the
Selection Sequence described for measurement
B) When OUT is selected, the instrument will execute the Selection
Sequence described for generation
Up to 50 program steps can be further divided in one or more routines
of different length.
4.1 - HOW TO CONSTRUCT AND STORE A NEW SEQUENTIAL
FUNCTION ROUTINE.
Push the PROG push-button; the display will show:
where:
YY indicates how many program steps are still available.
XX enter in this field the identification code number of the routine
to be created.
When it is desired to know the identification code already utilized,
depress s or t push-buttons. On the lower display line will appear
the identification code already in existence.
If the lower line is completely filled, depress s or t push-button
again to scroll the remaining codes.
NOTE: the identification codes are sorted in chronological order
and not in ascending order.
Type the desired identification code (e.g. 15) and then depress the
FUNC push-button.
PROGRAM N XX
YY FREE STEP(S)
PROGRAM N XX
1 7 5 3 12 15
PROGRAM N 15
RUN EDIT DEL
PROGRAM N 15 01
MEAS OUT SBY STO
M20-e-4.p65 7/9/01, 2:41 PM58
