55
Push the FUNC push-button; the cursor will go automatically on the
lower line.
By the numerical keyboard, set the desired read-out assigned to
the initial scale value (For Example 2, it is equal to 0.0 m
3
/h).
Depress the FUNC push-button.
NOTES:
1) The output range may contain negative values.
2) The displayed range will only be represented with positive
numbers.
The display will show the following:
By the numerical keyboard, set the desired final scale value (For
Example 2 it is equal to 5000 mV).
Push the FUNC push-button.
By the numerical keyboard, set the desired read-out assigned to
the final scale value (For Example 2 it is equal to 1500.0 (m
3
/h)).
Push the FUNC push-button.
NOTES:
1) The instrument will automatically select the output range
containing the two programmed values ("L.RANGE mV" and
"H.RANGE mV") with the maximum resolution.
2) For the read-out in eng. units, the number of decimal figures will
be equal to the decimal figure programmed in "L.RANGE EU".
3) By keeping depressed the s and/or t push-button it
overimposes a ramp up or down to the generated value with a
gradient of 2 LSD/second.
4) During a mV generation with programmable read-out scaling, it is
possible to enable/disable, by the REV/MOD push-button, the
scaling function and to display the generated value in mV.
The instrument will show:
By the numerical keyboard, set the value to be generate.
Push the FUNC push-button, the instrument start immediately to
generate.
H.RNG XXXXXX mV
H.RNG XXXXXX EU
OUT RNG(QUAD) mV
XXXXXX EU
